How-to Make an Excel Clustered Stacked Column Chart Type

Clustered Stacked Column Chart

How-to Make an Excel Clustered Stacked Column Chart Type

Have you been able to find the Excel Clustered Stacked Column Chart Type?

Clustered Stacked Column Chart

Well it is not there, unfortunately. But Excel is a powerful tool and we can user other options to create the chart we are looking for with this simple tip to make your own Excel Clustered Stacked Column graph. This tutorial is focused on Microsoft Excel 2013, Excel 2016 and Excel 2019. But it will most likely work for versions after 2019. If you want to see the steps required for Excel 20010 and Excel 2007, check out this tutorial: how-to-easily-create-a-stacked-clustered-column-chart-in-excel

The Breakdown

Here are the basic steps that we will walk through in this tutorial. The sample download file and video demonstration are at the end of the article.

1) Setup Data

2) Create Stacked Column Chart





3) Switch Rows/Columns of Chart (if needed)

4) Decrease Series Gap Width (as Desired)

Optional Steps for the Extended Chart Features:

5) Add Filler Series for Separation

5a) Insert Rows as Needed to Previously Created Chart

6) Add Vertical 2nd Axis Label Series

6a) Add Series

6b) Repeat Steps 2-3

6c) Move New Veritical 2nd Axis Label Series to 2nd Axis

6d) Change New Vertical 2nd Axis Label Series Fill to No Fill





6e) Decrease Series Gap Width (as Desired)

6f) Delete 2nd Axis Label Legend Entry

Step-by-Step

1) Setup Data

In order to create a simulated Clustered Stacked Column Chart type, we just need to perform 4 steps. Now this tip uses the Excel “Multi-level Category Labels” chart option for column charts. In order to use this option we need to setup our data in a certain way. So that is our first step.

Our scenario is that we are building a chart for the marketing team on amount spent and budgeted amount for 2 products on 4 media types (Print, Internet, TV, Radio). The data we received was in this format.





If you found the website and tutorials helpful, please consider donating to keep the lights on.

Donate with PayPal here:





ABCDEFGHI
1Sales Budget vs. Actual
2RadioRadioPrintPrintTVTVInternetInternet
3BudgetActualBudgetActualBudgetActualBudgetActual
4Product 112316615512891163181171
5Product 26314915710153140198153

Original Data



To utilize the ” Multi-level Category Labels” option in a column chart, we need to setup our data with tiered categories. That means that we have a main category in one column and many categories in the column to the right. Therefore, we need to change our data to the following format.

ABCDEF
1Sales Budget vs. Actual
2RadioPrintTVInternet
3Product 1Budget12315591181
4Actual166128163171
5Product 2Budget6315753198
6Actual149101140153

Basic Clustered Stacked Chart Setup



So you can see that our data has been rearranged so that Product 1 has 2 lines associated with it. One for the budget values and one for the actual values for all 4 types of media advertising. We are now ready to create the Excel Clustered Stacked Column chart.

2) Create Stacked Column Chart

To create our chart, highlight the data range in the data set above from A2:F6. Then go to the Insert Ribbon and click on the Stacked Column Chart in the chart button as you see here.

Clustered Stacked Column Create Chart Insert Chart

Your chart should now look like this:





Clustered Stacked Column Chart Initial Creation

3) Switch Rows/Columns of Chart (if needed)

Our chart doesn’t quite look right. In most cases you need to switch rows/columns on your chart. Why do I need to do this? Check out this video here

To fix your chart, simply click on the chart and then go to the Design Ribbon and click on the Switch Rows/Columns button.

Clustered Stacked Column Chart Switch Row Column Ribbon Button

Your chart is now complete and should look like this:

Clustered Stacked Column Chart After Switch Row Column

If you want to move the columns closer together follow the next step, but it is optional.

4) Decrease Series Gap Width (as Desired)

If you wish, and it is my preferred look, you can close the Gap Width of the columns. To do this, select the chart, and then select any data series and press CTRL+F1 (or right click and select Format Data Series). Then from the Format Data Series Dialog box, change the Gap Width to 15% or whatever you think looks best.

Clustered Stacked Column Chart Decrease Gap Width

Your final chart should now look like you see above. But we are not done if you want to add some additional changes. Below is completely optional and as you desire, but I think it adds some clarity and additional detail that will help the reader.

Optional Clustered Stacked Column Chart Steps

5) Add Filler Series for Separation

If you want to separate the groupings follow this step.

5a) Insert Rows as Needed to Previously Created Chart

Do this as you see fit, simply insert a row in your data and it will separate the groups.

Clustered Stacked Column Chart Optional Insert Row for Gap

After you insert your row, you then must follow steps 1-3 above to create your chart from the beginning. When you complete steps 1-3 you will then see that your chart doesn’t quite look right as your product 1 group includes this new space as you see here:

Clustered Stacked Column Chart Optional After Insert Row for Gap

To fix this, you need to fool Excel by creating another level one grouping that doesn’t show on the chart. This is very simple by just putting a space in the data set in the cell right above the Product 2 entry.





Clustered Stacked Column Chart Optional Add Space in Inserted Row for Gap

Your final chart with the added gap should look like this with the grouping fixed:

Clustered Stacked Column Chart Optional Gap Final

6) Add Vertical 2nd Axis Label Series

Optional Step 5 above looks good to me, but the product 2 data is farther away from the numbers so sometimes I like to add an additional chart series on the secondary axis to have the vertical axis numbers show closer to that series. This is an optional step, so only use it if you also like the look.

6a) Add Series

To make the secondary axis max limit value match the primary axis max limit, we need to create a formula for our additional secondary axis series. To do this, create a formula on the first row of data with a formula that calculates the maximum stacked column of all of the stacked columns that will be in the chart. Therefore, in cell G3, we create a MAX() formula with a sum of each row. See the Max and Sum formula below for more details.

ABCDEFG
1Sales Budget vs. Actual
2RadioPrintTVInternet2nd Axis Labels
3Product 1Budget12315591181628
4Actual166128163171
5
6Product 2Budget6315753198
7Actual149101140153

Optional 2nd Axis Chart



Worksheet Formulas
CellFormula
G3=MAX(SUM(C3:F3),SUM(C4:F4),SUM(C6:F6),SUM(C7:F7))

6b) Repeat Steps 2-3

Now that you have created your data set, you will simply follow all of the original basic steps 1-3 above to create your Clustered Stacked Column Chart but change your chart range to A2:G6 or A2:G7 if you have added an extra row for a gap between groupings. In my case I have added the gap row, so my chart range is A2:G7. Go ahead and create the initial chart as you see here:

Clustered Stacked Column Chart Optional 2nd Axis Insert Chart

Your chart initial should now look like this if you have the gap row in the data series after step 2.

After you Switch Rows/Columns your chart will look like this after step 3:

6c) Move New Veritical 2nd Axis Label Series to 2nd Axis

Our chart looks very similar to our basic chart, but there is an extra series that we will use for our secondary axis. So select the chart and then select the “2nd Axis Labels” series and press CTRL+F1 or right click on it and select the Format Data Series… option. This will bring up the option to move it to the Secondary Axis. Do that now.

6d) Change New Vertical 2nd Axis Label Series Fill to No Fill

When we moved the series to the secondary axis, it covers up one of our stacked columns. So to get around this, we need to change the fill on the series to No Fill. If you are still in the Format Data Series dialog box, click on the Fill Options (looks like a paint can pouring) and change the Fill to No Fill.

Clustered Stacked Column Chart Optional 2nd Axis Change to No Fill

6d) Decrease Series Gap Width (as Desired)

This is the same as optional step 4 above. I changed the gap width of the Stacked Columns on the Primary Axis to 15% as you see here:





Clustered Stacked Column Chart Optional 2nd Axis Decrease Gap on Primary Axis

6f) Delete 2nd Axis Label Legend Entry

Last thing we need to do is to delete the “2nd Axis Labels” legend entry on the Legend. To do this, select the chart and then select the legend and then select the legend and then select the “2nd Axis Labels” legend entry and press the delete key.

Clustered Stacked Column Chart Optional 2nd Axis Delete Legend Entry

Your final chart will now look like this:

Clustered Stacked Column Chart Optional Final

This is a great technique to make a combo chart that is frequently needed for complex data sets. It will even work for more product data sets. Here is sample of what another series would look like.

Clustered Stacked Column Chart

Video Demonstration

Check out this Video tutorial on the techniques presented above.


Sample File Download

Click here to Download the Free Sample Excel Template File:
Clustered-Stacked-Column-Charts

What do you think of this technique? Do you think that Microsoft should add this as a chart type in Excel? Let me know what you think in the comments below.
